JR XG 14 User Manual

58
▋▋Name▋of▋the▋Master▋Channel▋and▋its▋purposes.▋
Explanation▋of▋the▋“INCLUDE”▋function.
▋▋INCLUDE
If there are several sets of Mixing set on the program mixing, there
is no connection between those Mixing each other. If the “INCLUDE”
setting is used provided, it is capable to include relevant mixing to
be set in one Mixing to avoid complexity , It simplies the mixing
set up. As an example, Right drawing shows Mixing set up in order
to reduce certain tendency of the airplane. Say there is a Mixing
Aileron to Elevator and Elevator and Rudder mixing independently.
However on this mixing there is no connection between Aileron to
the Rudder, so it require to set another mixing as such. However, if
you set up the INCLUDE function on the MIXING “B”
whole mixing will be as right hand side of the drawing.
So Mixing “B” included with MIXING “A”. Per this set
up it reduces the complexity and simplies the mixing.
▋▋For▋Helicopter
Channel name Items which can be Included
Ch1: Throttle (THRO)
Throttle trim, Throttle Curve (THROCURVE), Throttle Mixing (MIX → THRO),Throttle hold
(THROHOLD), Throttle Cut (THROCUT)
Ch2: Aileron (AILE) Aileron trim, Dual Rate, (D/R&EXP)
Ch3: Elevator (ELEV) Elevator Trim, Dual Rate (D/R&EXP)
Ch4: Rudder (RUDD) Rudder Trim, Dual Rate, (D/R&EXP)
Ch5: Gear (GEAR)
Ch6: Pitch (PIT.) Pitch Curve (PIT.CURVE)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
Extra: FMOD The mixing can be coupled to the Flight Mode Switch.
TRNR The mixing can be coupled to the Trainer switch.
NEDL Channel which is allocated for Needle setting.
▋▋For▋Airplane
Channel name Items which can be Included
Ch1: Throttle (THRO) Throttle trim, Throttle curve (THRO CURVE), Throttle cut (THRO CUT)
Ch2: Aileron (AILE) Aileron trim, Dual Rate (D/R&EXP), Flap system (FLAP SYSTEM)
Ch3: Elevator (ELEV) Elevator Trim, Dual Rate (D/R&EXP), Flap system (FLAP SYSTEM)
Ch4: Rudder (RUDD) Rudder Trim, Dual Rate (D/R&EXP)
Ch5: Gear (GEAR)
Ch6: Flap (FLAP) Flap Trim, Flap System (FLAPSYS)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
Extra: LTRM Mixing from Left side Trim (AUXTRIM).
LLVR Mixing from Left side Lever (AUX3LEVER).
RTRM Mixing from Right side Trim (FLAPTRIM).
RLVR Mixing from Right side Lever (FLAPLEVER).
SNAP Mixing from SnapRoll Switch (SNAPSW).
Function▋List
Hold Delay (HOLD DELAY)
Hold Position
Rudder
Aileron
Additional Mixing
Elevator
Aileron
Mixing A
Rudder
Elevator
Mixing B
Elevator
Aileron
Rudder
Mixing A Mixing B
(INCLUDED Function)
