5─20
5.2 ATA OPERATION
yy
yyy
5
An example of display is shown in Fig. 5-4
Fig. 5-4 Example of Display (in North-up and True Vector mode)
In addition to the marks and symbols shown above, fixed/variable range markers, electronic bearing lines, etc.
are presented on an actual video.
Trackball (Cursor Mark)
Lost Target
Guard Zone
Target intruding the Guard Zone
Dangerous Target
Past Positions
(Changed Course)
Safe Target
Past positions
(Straight Course)
NAV Lines
Untracked Target
HL
