Monitor Test
1. Pattern 1
2. Pattern 2
3. Pattern 3
4. Pattern 4
5. Pattern 5
0. EXIT
[II] Monitor Test
Checks for the monitor.
Procedures 1 Press [2] key while the Test Menu is
open.
The Monitor Test Menu will appear.
2 Select the item number you want to
display, pressing numeric keys [1] to
[5] of the test pattern.
The selected test pattern will be displayed.
Pattern 1: All colors are filled with white.
Pattern 2: A white box is displayed on the black background of
1024 × 768 dots.
Pattern 3: Displays rectangle × 2, circle × 2, and cross-shape×
13 (white lines on the black background).
Pattern 4: Displays “H” of 9 dots × 9 dots on the entire screen
(white character on the black background).
Pattern 5: Gray scale display (16 levels)
Pattern 6: Displays a color bar.
3 To return to the original display, press
any key.
If errors occur in the monitor, no test pattern
will appear.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
