GPS (LL/COG/SOG)
1. GGA
USE
2. RMC
USE
USE
0. EXIT
3. RMA
USE
4. GNS
5. GLL
6. VTG
USE
USE
[II] Reception Sentence Setting (RX Sentence)
Set signal sentences to be received from sensors.
Procedures 1 Open the Equipment Setup Menu.
2 Press [5] key.
The COM Port Setting Menu will appear.
3 Press [2] key.
The RX Sentence Menu will appear.
4 Select the signal you want to set,
pressing the numeric keys [1] to [3].
The Setting Menu for each signal will appear.
Settable signal
1. GPS (LL/COG/SOG)
2. GPS (WPT/Time)
3. Depth
4. Wind
5. Current
↓
↓
5 Select whether or not you want to use
sentence for the signal.
Types of sentences to be used
GPS (LL/COG/SOG): GGA/RMC/RMA/GNS/
GLL/VTG
GPS (WPT/Time): GGA/RMC/RMB/
BWC/BWR/ZDA
Depth: DPT/DBK/DBT/DBS
Wind: MWV/MWD
Current: CUR
After having selected a signal, choose the
number of the sentence for which you want to
set whether or not it is used, pressing the
numeric key.
As concerns current, set data set number and
layer number of CUR sentence.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
RX Sentence
1. GPS (LL/COG/SOG) >
2. GPS (WPT/Time) >
0. EXIT
3. Depth >
5. Current >
4. Wind >
