8─95
The following items are to appear on the Status display.
DATE/TIME : Local date and time
(UTC) : Greenwich Mean Time
L/L : Current latitude and longitude
FIX MODE : Fix Mode (2D positioning/3D positioning)
ALT : Altitude of own ship. Setting the Fix Mode to 2D displays the antenna height initially
set.
DOP LEVEL : Precision of positioning results. As the value is smaller, the indicated precision is
higher.
SATELLITE No. : Satellite No.
FIX : Is positioning data used?
AZIMUTH : Azimuthal angle of satellite
ELEVATE : Elevation angle of satellite
LEVEL : Reception signal level
STATUS : Current status of satellite
RSSI : Reception intensity of Beacon station
