2─12
2
2.2 FUNCTIONS OF SOFTWARE BUTTONS
yy
→See section 3.5.3 on page 3-26.
: Numeric data display mode of EBL2
Selects the numeric data display mode of EBL2 depending on the true or relative bearing. The
selection changes each time the button is pressed.
T is displayed while true bearing is selected; R is displayed while relative bearing is
selected.
→See section 3.5.3 on page 3-26.
: Memory intervals for own ship track display
Selects track data memory intervals for own ship. The setting changes each time the button is
pressed.
→See section 3.6.2 on page 3-68/70.
: Selection of units of memory intervals for own ship’s track display
Selects units of memory intervals for own ship’s track display. The selection switches back and
forth between
sec → min and nm each time the button is clicked.
→See section 3.6.2 on page 3-68.
: Selection of bearing sensor
The bearing sensor in use is displayed.
: Selection of speed sensor
Selects a speed sensor. The selection changes in the following sequence each time the button is
pressed.
MAN → LOG → 2AXW → 2AXG → GPS
(Manual) (1-axis log) (2-axis log water) (2-axis ground)
An alarm occurs if a speed sensor not connected to the radar is selected.
While MAN is selected for the speed sensor, a value can be entered by moving the cursor to
the value area and left-clicking.
: Selection of time display mode
Selects UTC or LOCAL for the time display mode. The selection changes each time the
button is pressed.
UTC: Universal time coordinated
LOCAL: Local time
→See section 8.6 on page 8-96.
