2─13
: SET/DRIFT
Turns on/off the SET/DRIFT correction.
If CORRECTION is on, CORR is displayed beside the button. In this case, the values
shown to the right of CORR are valid. CORRECTION can be selected only when
MANUAL or LOG (1-axis log) or 2AXW (2-axis log speed against water) is selected for
the speed sensor.
SET setting
To enter a value, move the cursor to the value area and left-click.
This setting is valid only when CORRECTION is set to ON.
DRIFT setting
To enter a value, move the cursor to the value area and left-click.
This setting is valid only when CORRECTION is set to ON.
→See section 8.6 on page 8-73.
: ATA vector mode
Selects a vector mode for ATA symbol display.
T: Indicates true vector. R: Indicates relative vector.
This selection changes with the PAST POSN (past position) display mode.
→See section 5.2.4 on page 5-16.
: PAST POSN display mode
Selects a display mode for ATA’s PAST POSN.
T : Indicates true past position. R : Indicates relative past position.
This selection changes with the ATA vector mode.
→See section 5.2.4 on page 5-19.
: Guard zone 1 function ON/OFF
Sets the guard zone 1 function to ON or OFF.
→See section 5.2.1 on page 5-12.
: Guard zone 2 function ON/OFF
Sets the guard zone 2 function to ON or OFF.
→See section 5.2.1 on page 5-12.
, : Scroll of ATA numeric data display
Pressing either of the buttons scrolls the target ship IDs in the ATA numeric data display area.
→See section 5.2.5 on page 5-21.
: ATA TARGET display
Displays the ATA numeric data display screen when pressed while the menu screen is open.
: RADAR menu
This button operates similarly to the [RADAR MENU] key on the control panel.
Press the button to open the “MAIN MENU” screen.
: ATA menu
This button operates similarly to the [ATA MENU] key on the control panel.
Press the button to open the “ATA MENU” screen.
Use this menu screen to set the ATA function and AIS function.
: PLOT menu
Press this button to open the “PLOT MENU” screen.
Use this menu screen to set the plotter function.
