JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
3－55
3
3.6.3.3 Deleting a mark or line (Delete)
With regard to the created user map, a mark or line is deleted individually.
Procedures
1) Open the Edit User Map menu by performing the following menu
operation.
→
The Edit User Map menu will appear.
2) Left-click the button.
The user map delete mode is selected.
is displayed in the cursor mode located at the upper right of the display.
3) Put the cursor on a mark or line, and left-click.
The entire selected mark or line is deleted.
To delete another mark or line, repeat procedures 3 and 4.
4) When finished with the correction of all items, left-click the
button.
The cursor mode changes to the normal operation mode, terminating the user map delete
mode.
U.Map
2. Edit User Map
4. Delete
Delete
0.Exit
