JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
3.6.3.4 Inserting a vertex into a line (Insert/Move Vertex)
With regard to the created user map, a vertex is inserted into a line.
Procedures
1) Open the Edit User Map menu by performing the following menu
operation.
āć
The Edit User Map menu will appear.
2) Left-click the button.
The user map insert/correction mode is selected.
is displayed in the cursor mode located the upper right of the display.
3) Put the cursor to a side line into which a vertex will be inserted,
and left-click.
A vertex is inserted into the selected line, and the cursor mark will be displayed.
4) Move the cursor mark to the newly inserted vertex, and left-
click.
To insert another vertex, repeat procedures 3 and 4.
5) When finished with the correction of all items, left-click the
button.
The cursor mode changes to the normal operation mode, terminating the user map insertion/
correction mode.
U.Map
2. Edit User Map
5. Insert /Move Vertex
Insert/Move
0.Exit
