JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3ļ¼69
3
Procedures
1) Open the Set Route Sequence menu by performing the menu
operation below.
āć
āć
2) Left-click the button.
Confirmation Window will appear.
3) Left-click the button.
The saved route data will be deleted.
3.7.2.2 Adding a Waypoint (Add Waypoint)
New Waypoint data is added to the route data saved in the radar system.
Procedures
1) Open the Set Route Sequence menu by performing the menu
operation below.
āć
āć
2) Left-click the button.
The Waypoint adding mode is selected.
The rubber band from the last Waypoint to the cursor position will be displayed on the radar
display.
3) Left-click the location at which you want to add a Waypoint.
A Waypoint will be added.
When a Waypoint is added, the value of the Planned Speed in the section up to the menu is
used for the Planned Speed value up to the added Waypoint.
Route
2. WPT/Route Setting
3. Set Route Sequence
7. New Monitor Route
1. Yes
Route
2. WPT/Route Setting
3. Set Route Sequence
2. Add
To Next Page
