JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3－107
3
[4] Depth Unit
• Set the unit of water depth for the water-depth graph.
3.8.8.4 Wind Graph Setting
• The Wind Graph Setting menu will appear.
[1] Wind Graph Display
• Determine whether to display received wind direction/velocity information
with a graph.
• One of two digital information areas is used to display data.
• When the wind direction / speed graph is displayed, the sizes of the target
tracking (TT) / AIS numeric data display areas are exclusively decreased.
• Left-click the button located at thelower righit of the display. The
wind direction / speed graph display function is switched between On and Off.
[2] Wind Speed Unit
• Set the unit of wind velocity for the wind direction / speed graph.
: Sets 10 minutes as the time range.
: Sets 15 minutes as the time range.
: Sets 30 minutes as the time range.
: Sets 60 minutes as the time range.
: Sets 12 hours as the time range.
: The foot is used as the unit of water depth.
: The fathom is used as the unit of water depth.
: The meter is used as the unit of water depth.
: Does not display the wind direction / speed graph.
: Displays the wind direction / speed graph in digital information area 1.
: Displays the wind direction / speed graph in digital information area 2.
: Meters per second are used as the unit of wind speed.
: Kirometers per hour are used as the unit of wind speed.
: Knots are used as the unit of wind speed.
10min
15min
30min
60min
12hour
Feet
Fathom
Meters
Target
Off
Area1
Area2
m/s
km/h
kn
