JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3.8.8.5 TEMP Graph Setting
ā¢ The TEMP Graph Setting menu will appear.
[1] TEMP Graph Display
ā¢ Determine whether to display the graph of the water-temperature data that has
been received on the radar display.
ā¢ One of two digital information areas is used to display data.
ā¢ When the water-temperature graph is displayed, the sizes of the target tracking
(TT)/AIS numeric data display areas are exclusively decreased.
ā¢ Left-click the button located at thelower righit of the display. The
water-temperature graph display function is switched between On and Off.
[2] TEMP Graph Color
ā¢ Set the color for the water-temperature graph.
ā¢ There are eight selection items:
, , , , , ,
[3] TEMP Range
ā¢ When Color is selected for the display color for the water-temperature graph,
set the temperature range of each color.
[4] Time Range
ā¢ Set the time range for the water-temperature graph.
: The water-temperature graph is not displayed.
: The water-temperature graph is displayed in digital information area 1.
: The water-temperature graph is displayed in digital information area 2.
: The time range is set at 10 minutes.
: The time range is set at 15 minutes.
: The time range is set at 30 minutes.
: The time range is set at 60 minutes.
: The time range is set at 12 hours.
Target
Off
Area1
Area2
White Gray Blue Green Yellow Pink Red
10min
15min
30min
60min
12hour
