JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.9 USE FUNCTION KEY [USER]
page 5-[3] Small Buoy Detection
ā¢ Reduces the loss of signal processing during detection of small targets.
page 5-[4] FishNet Detection
ā¢ Use this mode to detect small targets hidden by sea clutter returns.
ā¢ This function becomes more effective when the AUTO RAIN clutter
suppression function is used together.
page 5-[5] Antenna Height
ā¢ Set the height of radar antenna above sea level.
ā¢ The STC/FTC curve is changed.
:Activates the general signal processing mode.
:Activates the small buoy detection mode that reduces the loss
of signal processing.
:Activates the general signal processing mode.
:Activates the fishnet detection mode.
: Set default
: Set the antenna height under 5m.
: Set the antenna height 5m to 10m.
: Set the antenna height 10m to 20m.
: Set the antenna height over 20m.
Off
On
Off
On
Default
~5m
5m~10m
10m~20m
20m~
To Next Page
