JRC JMA-9110-6XA User Manual

9－14
JMA-9100 Instruction Manual > 9.TROUBLE SHOOTING AND AFTER-SALES SERVICE > 9.2 TROUBLE SHOOTING
Tab l e 9- 21： Circuit Block to be Repaired (JMA-9133-SA)
Location Circuit Block Type Remarks
SCANNER UNIT
MOTOR
MDBW10823*
i
For 100/220VAC
SCANNER UNIT
ENCODER
CHT-71A
SCANNER UNIT
AC220V MOTOR DRIVER
H-7EPRD0034* For 220VAC
SCANNER UNIT
AC100V MOTOR DRIVER
H-7EPRD0035* For 100VAC
SCANNER UNIT
PERFORMANCE MONITOR
NJU-84
SCANNER UNIT
BRAKE CIRCUIT
CFA-255
SCANNER UNIT
BRAKE CONTROL CIRCUIT
CCB-655
SCANNER UNIT
BRAKE UNIT
NZR-17 Including CFA-261/262
TRANSMITTER
RECEIVER UNIT
T/R CONTROL CIRCUIT
CMC-1205R
TRANSMITTER
RECEIVER UNIT
MODULATOR UNIT
NMA-553-1 Including CPA-264, CMB-
407 and CFR-229
Exluding Magnetron
TRANSMITTER
RECEIVER UNIT
MODULATOR CIRCUIT
CPA-264
TRANSMITTER
RECEIVER UNIT
RECEIVER UNIT
NRG-229
TRANSMITTER
RECEIVER UNIT
POWER SUPPLY CIRCUIT
CBD-1682A
TRANSMITTER
RECEIVER UNIT
RELAY FILTER CIRCUIT
CSC-656
RADAR PROCESS UNIT
RADAR PROCESS CIRCUIT
MPBC44213*
CDC-1324 with mounting
bracket, CDC-1325 and
CDC-1186D
RADAR PROCESS UNIT
RADAR PROCESS CIRCUIT
MDLW11900*
CDC-1324 with mounting
bracket
RADAR PROCESS UNIT
AIS PROCESS CIRCUIT
CDC-1325
RADAR PROCESS UNIT
ARPA PROCESS CIRCUIT
CDC-1186D
RADAR PROCESS UNIT
GYRO INTERFACE CIRCUIT
CMJ-462E
RADAR PROCESS UNIT
TERMINAL BOARD
CQD-2097A
RADAR PROCESS UNIT
MOTHER BOARD
CQC-1192
RADAR PROCESS UNIT
FAN (RPU)
109R0612S4D13
RADAR PROCESS UNIT
POWER SUPPLY
CBD-1661
RADAR PROCESS UNIT
FAN (PSU)
H-7BFRD0006*
OPERATION UNIT
OPERATION CIRCUIT A
CCK-973
OPERATION UNIT
OPERATION CIRCUIT B
CCK-974
OPERATION UNIT
OPERATION CIRCUIT D
CCK-976
OPERATION UNIT
TRACKBALL
CCK-1013
MONITOR UNIT
BEZEL KIT
MPXP34376* Radar bezel kit
MONITOR UNIT
23 inch LCD
CML-799L 23.1-inch LCD PANEL
MONITOR UNIT
LCD OPERATION CIRCUIT
CCK-972
i. “*” means revision, such as A, B and so on.
