115
–
2) Level 2
Memory switch data (level 2) can be edited when pressing MODE switch for as long as 6 seconds.
Pedal stroke
0
2
1
Number
of
rotation
No. Item
Setting range
Edit unit
Initial display
Presser position after thread trimming selection
Position of the presser after thread trimming is set.
: DOWN : UP
– – – – – – UP
Max. sewing speed setting
Max. sewing speed of the sewing machine is set.
200 to
3500
10sti/min 3500sti/
min
Sewing speed at low speed setting
Min. sewing speed of the sewing machine is set.
200 to 400 5sti/min 200sti/min
Sewing speed of thread trimming setting
Sewing speed at the time of thread
100 to 250 5sti/min 160sti/min
This function is set when hand lamp ickers.
0 : Without icker reduction function
1 : Less effective
/
8 : more effective
0 to 8 1 0
Rotation start pedal stroke setting
Stroke from the neutral position of pedal to sewing
machine rotation start position is set.
1.0 to 5.0 0.1mm 3.0mm
Pedal low speed section
Section from pedal neutral position to sewing
machine acceleration start position is set.
1.0 to 10.0 0.1mm 6.0mm
Pedal presser lifting start position
Section from pedal neutral position to cloth
presser lifting start position is set.
– 1.0 to –
6.0
0.1mm – 2.1mm
Thread trimming start pedal stroke
Section from pedal neutral position to thread
trimming start position is set.
– 1.0 to –
6.0
0.1mm – 5.1mm
Pedal max. number of rotation reach stroke
Section from pedal neutral position to max. num-
ber of rotation reach position is set.
1.0 to 15.0 0.1mm 15.0mm
Pedal neutral position compensation
Compensation value of neutral point of pedal
is set.
– 15 to 15 1 – 1
Auto-lifter lifting holding time
Waiting time of lifting the presser lifter is set.
10 to 600 10sec 60sec
Pedal curve selection function
Curve of the number of rotation of the sewing machine in
terms of pedal depressing amount is selected.
0 : Straight line 1 : Square
2 : Square root
– – – – – – Straight
line
