Table 31: Console Port Connector Pinouts for the QFX Series (continued)
DescriptionSignalPin
Receive dataRxD Input6
Data carrier detectDCD Input7
Clear to sendCTS Input8
Related
Documentation
Connecting a QFX Series Device to a Management Console on page 179•
Management Port Connector Pinouts for the QFX Series
The 1000BASE-T RJ-45 management ports use an RJ-45 connector to connect either
to the control plane and management network in a QFabric system, or to a management
device for out-of-band management.
Table 32 on page 85 provides the pinout information of the RJ-45 management port
connector. An RJ-45 cable is supplied with the QFX Series device.
NOTE: The RJ-45 pinout information in Table 32 on page 85 also applies to
the QFX5100-48T device 10GBASE-T access ports.
Table 32: RJ-45 Management Port Connector Pinouts for the QFX Series
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1–2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4–8
Related
Documentation
Management Port LEDs on a QFX3100 Director Device•
• Management Port LEDs in the QFX3600 and QFX3600-I Device
• Management Port LEDs on a QFX3500 Device
85Copyright © 2016, Juniper Networks, Inc.
Chapter 8: Port and Interface Specifications

Juniper QFX5100 Specifications

General

Model	QFX5100
Category	Switch
Power Supply	Dual, hot-swappable
Rack Units	1U
Junos OS	Junos OS
Form Factor	Fixed
Management Ports	1x RJ-45
Other Ports	1 x USB port
Operating Temperature	0°C to 40°C
Storage Temperature	-40° to 158° F (-40° to 70° C)
Humidity	5% to 90% non-condensing
Power Consumption	Varies by model
AC Input Voltage	100-240 VAC
AC Input Frequency	50 to 60 Hz
Maximum Power Consumption	400W
Mean Time Between Failures (MTBF)	200, 000 hours
Ports	48x 10GbE SFP+ and 6x 40GbE QSFP+
