Figure 85: Installing an SFP Transceiver in the QFX Series
Figure 86: Installing a QSFP+ Transceiver in the QFX Series—Vertical
Orientation
g050117
QSFP
transceiver
Figure 87: Installing a QSFP+ Transceiver in the QFX Series—Horizontal
Orientation
g050224
Figure 88: Installing a QSFP+ Transceiver in a QFX5100-48T
