Table 37: Copper Interface Support and Optical Interface Support for Gigabit Ethernet SFP

Transceivers for the QFX Series

Specifications

Standards

Compliance

QFX-SFP-1GE-TProduct SKU

number

1000BASE-T

NOTE: On

QFX5100-48S and

QFX5100-96S

devices, this

transceiver can be

forced to 100 Mbps

speed using the set

interface speed

command.

QFX3008-I

QFX3500

QFX5100-24Q (management ports only)

QFX5100-48S

QFX5100-48T (management port only)

QFX5100-96S

Supported models

1.25 GBd +/- 100 ppmSignaling rate

(range)

RJ-45Connector type

–Fiber pairs

–Transmit and

receive wavelength

–Average transmit

launch power

(minimum)

–Average transmit

launch power

(maximum)

–Average receive

power (maximum)

–Receive sensitivity

Not availableDOM support

–Fiber type

100 m (328 ft)Operating range
