Juniper QFX5100 User Manual

Table 44: QSFP+ to QSFP+ Active Optical Cables (continued)
Value
Characteristic
1 m (3.3 ft.)JNP-40G-AOC-1MOperating range
3 m (9.8 ft.)JNP-40G-AOC-3M
5 m (16.4 ft.)JNP-40G-AOC-5M
7 m (22.9 ft.)JNP-40G-AOC-7M
10 m (32.8 ft.)JNP-40G-AOC-10M
15 m (49.2 ft.)JNP-40G-AOC-15M
20 m (65.6 ft.)JNP-40G-AOC-20M
30 m (98.4 ft.)JNP-40G-AOC-30M
Laser bias current–supported
RX input power–supported
Case temperature–supported
Power supply voltage–supported
Laser output power–not supported
Diagnostic support
14.1X53-D35Minimum Junos OS release
Related
Documentation
Interface Support for the QFX5100 Device on page 86•
Interface Specifications for QSFP+ to SFP+ Active Optical Breakout Cables for the
QFX5100
A 40-Gigabit Ethernet active optical breakout cable (AOCBO) is a four-fiber assembly
that has an QSFP+ transceiver permanently attached to one end and has four SFP+
transceivers attached to the individual fibers at the other end.
Use Table 45 on page 135 to locate the specifications for 40-Gigabit Ethernet AOCBO.
Copyright © 2016, Juniper Networks, Inc.134
QFX5100 Switch Hardware Guide

Juniper QFX5100 Specifications

General

Model	QFX5100
Category	Switch
Power Supply	Dual, hot-swappable
Rack Units	1U
Junos OS	Junos OS
Form Factor	Fixed
Management Ports	1x RJ-45
Other Ports	1 x USB port
Operating Temperature	0°C to 40°C
Storage Temperature	-40° to 158° F (-40° to 70° C)
Humidity	5% to 90% non-condensing
Power Consumption	Varies by model
AC Input Voltage	100-240 VAC
AC Input Frequency	50 to 60 Hz
Maximum Power Consumption	400W
Mean Time Between Failures (MTBF)	200, 000 hours
Ports	48x 10GbE SFP+ and 6x 40GbE QSFP+
