Table 53: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts (continued)
PinPin
112
Related
Documentation
Interface Support for the QFX3500 Device•
• Interface Support for the QFX3600 Device
• Interface Support for the QFX5100 Device on page 86
• QFX5200 Optical Interface Support
• Interface Support for the QFX10002
• QFX10000 Optical Transceiver and Cable Support
Cable Specifications for Console and Management Connections for the QFX Series
Table 54 on page 149 lists the specifications for the cables that connect the QFX Series
to a management device.
NOTE: The QFX Series can be configured with SFP management ports that
support 1000BASE-SX transceivers. See “Interface Specifications for SFP,
SFP+, and QSFP+ Transceivers for the QFX Series” on page 94 for more on
the fiber-optic cables required for use with these transceivers.
Table 54: Cable Specifications for Console and Management Connections for the QFX Series
Device
ReceptacleMaximum LengthCable SuppliedCable Specification
PortonQFXSeries
Device
RJ-457 feet (2.13 meters)One 7-foot (2.13-meter) long
RJ-45 patch cable and RJ-45 to
DB-9 adapter
RS-232(EIA-232) serial cableConsole port
RJ-45328 feet
(100 meters)
One 7-foot (2.13-meter) long
RJ-45 patch cable
Category 5 cable or
equivalent suitable for
1000BASE-T operation
Management port
Related
Documentation
Console Port Connector Pinouts for the QFX Series on page 84•
• Management Port Connector Pinouts for the QFX Series on page 85
• Connecting a QFX Series Device to a Management Console on page 179
• Connecting a QFX3600 Device to a Network for Out-of-Band Management
• Connecting a QFX3500 Device to a Network for Out-of-Band Management
• Connecting a QFX3100 Director Device to a Network for Out-of-Band Management
• Connecting a QFX5100 Device to a Networkfor Out-of-Band Management on page 180
149Copyright © 2016, Juniper Networks, Inc.
Chapter 9: Cable Specifications
