Figure 35: Management Port LEDs on a QFX5100 Switch
4—1— em0–RJ-45 (10/100/1000 Base-T)
management Ethernet port (C0)
Status LEDs
5—2— RJ-45 console port (CON)em1–SFP management Ethernet port (C1)
Cage (socket foreither 10/100/1000 Base-T
RJ45 SFP or 1GbE fiber SFP)
6—3— USB port
Reset button,seecaution statement below
CAUTION: Do not use the Reset button to restart the power sequence unless
under the direction of Juniper Networks Technical Assistance Center (JTAC).
Table 14 on page 57 describes the management port LEDs.
