Table 38: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for the QFX

Series (continued)

Specifications

Standards

Compliance

QFX-SFP-10GE-USRProduct SKU

number

Juniper Networks

proprietary 10G-USR

QFX3500

QFX5100-24Q (management ports only)

QFX5100-48S

QFX5100-48T (management ports only)

QFX5100-96S

Supported models

9.95328 GBd +/- 20 ppm

10.3125 GBd +/- 100 ppm

Signaling rate

LC/PCConnector type

1Fiber pairs

840 nm to 860 nmCenter wavelength

(range

0.65 nmRMS spectral

width (maximum)

-7.3 dBmAverage transmit

launch power

(minimum)

-1.3 dBmAverage transmit

launch power

(maximum)

-9.9 dBmAverage receive

power (minimum)

-1.0 dBmAverage receive

power (maximum)

-11.1 dBmReceiver sensitivity

(OMA)

(maximum)

AvailableDOM support

MMFFiber type
