Table 38: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for the QFX

Series (continued)

Specifications

Standards

Compliance

QFX-SFP-10GE-ERProduct SKU

number

10GBASE-ER

QFX3500

QFX5100-24Q (management ports only)

QFX5100-48S

QFX5100-48T (management port only)

QFX5100-96S

Supported models

9.95328 GBd +/- 20 ppm

10.3125 GBd +/- 100 ppm

Signaling rate

LC/ultra physical connector (UPC)Connector type

1Fiber pairs

1530 nm to 1565 nmCenterwavelength

(range)

-4.7 dBmAverage transmit

launch power

(minimum)

4.0 dBmAverage transmit

launch power

(maximum)

-15.8 dBmAverage receive

power (minimum)

-1.0 dBmAverage receive

power (maximum)

-14.1 dBmReceiver sensitivity

(OMA)

(maximum)

-11.3 dBmStressed receiver

sensitivity

(maximum) in

OMA

AvailableDOM support
