Keithley 2110 User Manual

Section
5: Remote commands Model 2110 5½ Digit Multimeter
Reference Manual
5-12 2110-901-01 Rev. C/August 2013
Using common commands and SCPI commands in the same message
Both common commands and SCPI commands can be used in the same message as long as they
are separated by semicolons (;). A common command can be executed at any command level and
will not affect the path pointer. For example:
:stat:ques:enab <n>; *ESE <n>
Program message terminator (PMT)
Each program message must be terminated with a LF (line feed), EOI (end or identify), or an LF+EOI.
The bus will hang if your computer does not provide this termination. The following example shows
how a multiple command program message must be terminated:
*rst;*cls <PMT>
Command execution rules
Command execution rules are as follows:
• Commands execute in the order that they are presented in the program message.
• An invalid command generates an error and is not executed.
• Valid commands that precede an invalid command in a multiple command program message are
executed.
• Valid commands that follow an invalid command in a multiple command program message are
ignored.
Output Data
Type
The instrument provides the following types of output data:
• Non-reading queries
• Single reading (IEEE-488.2)
• Multiple readings (IEEE-488.2)
• Single reading (USB)
• Multiple readings (USB)

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
