Keithley 2110 User Manual

M
odel 2110 5½ Digit Multimeter Reference Manual Section 5:
Remote commands
2110-901-01 Rev. C/August 2013 5-59
[SENSe:]TEMPerature:SPRTD:DX <n>|MIN|MAX
Use this command to set the DX coefficient for the SPRTD sensor.
Parameters
<n> description
-1.1 to +1.1
Select the DX coefficient for the SPRTD sensor.
MINimum
Select the minimum coefficient.
MAXimum
Select the maximum coefficient.
Query
command description
[SENSe:]TEMPerature:SPRTD:DX?
Query the sensor DX coefficient.
[SENSe:]TEMPerature:SPRTD:DX? MIN
Query the minimum sensor DX coefficient.
[SENSe:]TEMPerature:SPRTD:DX? MAX
Query the maximum sensor DX coefficient.
Details
Refer to the following topic in the Temperature measurement (on page 3-17) section for more information about
the DX coefficient: RTD coefficients and temperature calculation (on page 3-19).
[SENSe:]TEMPerature:TRANsducer <name>
Use this command to select the temperature transducer type.
Parameters
<name> description
RTD
Select 2-wire RTD.
FRTD
Select 4-wire RTD (also works with 3-wire RTD).
Query
command description
[SENSe:]TEMPerature:TRANsducer:TY
PE?
Query the temperature transducer type.
Details
Refer to the following topic in the Temperature measurement (on page 3-17) section for more information about
RTD measurement: RTD coefficients and temperature calculation (on page 3-19).

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
