Keithley 2110 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 5:
Remote commands
2110-901-01 Rev. C/August 2013 5-27
CALCulate subsystem
The commands in this subsystem configure and control the Calculate subsystems and are
summarized in CALCulate subsystem summary (on page 5-20
).
There are seven math operations. Only one of them can be enabled at a time. They either store data
for later use or perform mathematical operations on the readings. See Math operations (on page
3-
48) for more details.
CALCulate:AVERage:AVERage?
This command reads the average value of all readings taken since the averaging operation was enabled. The
instrument clears the value when averaging is turned on, when the power is turned off, or a remote interface reset
occurs.
CALCulate:AVERage:COUNt?
This command reads the average value of all readings taken since averaging was enabled. The instrument clears
the value when averaging is turned on, when the power is turned off, or a remote interface reset occurs.
CALCulate:AVERage:MINimum?
This command reads the minimum value found during the averaging operation. The instrument clears the value
when averaging is turned on, when the power is turned off, or a remote interface reset occurs.
CALCulate:AVERage:MAXimum?
This command reads the maximum value found during the averaging operation. The instrument clears the value
when averaging is turned on, when the power is turned off, or a remote interface reset occurs.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
