Keithley 2110 User Manual

Section
1: Introduction Model 2110 5½ Digit Multimeter
Reference Manual
1-6 2110-901-01 Rev. C/August 2013
Figure 2: Dimensions
Power-on settings
See the following table for information about the Model 2110 factory default settings. These settings
are also restored when the instrument is turned on and when the instrument receives a *RST
command from a remote interface.
Function Default
Function displayed after the instrument is turned on
DC voltage
Auto zero
ON
Frequency and period source
AC voltage
Output format
ASCII
Ratio
OFF
AC voltage
Frequency
20 Hz
AC digits
5.5
Range
10 V
DC voltage
DC digits
5.5 (1 PLC)
Range
1 V
AC current
Frequency
20 Hz
AC digits
5.5
Range
1 A
DC current
DC digits
5.5 (1 PLC)
Range
1 A
Frequency and period
Digits
5.5
Range
10 V
Gate time
0.1 s
Capacitance
Digits
4.5
Range 10 nF

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
