5: Remote commands Model 2110 5½ Digit Multimeter
Reference Manual
5-38 2110-901-01 Rev. C/August 2013
[SENSe:]CURRent[:DC]:NPLCycles <n>|MIN|MAX
Use this command to select the integration time for DC current measurements. Integration time for DCI
measurements is expressed as the number of power line cycles (NPLC).
Parameters
<n> description
0.001
Select 0.001 NPLC.
0.006
Select 0.006 NPLC.
0.02
Select 0.02 NPLC.
0.06
Select 0.06 NPLC.
0.2
Select 0.2 NPLC.
0.6
Select 0.6 NPLC.
1
Select 1 NPLC.
2
Select 2 NPLC.
10
Select 10 NPLC.
100
Select 100 NPLC.
MINimum
Select the minimum value.
MAXimum
Select the maximum value.
Query
command description
[SENSe:]CURRent[:DC]:NPLCycles?
Query the NPLCycles.
[SENSe:]CURRent[:DC]:NPLCycles? MIN
Query the minimum value.
[SENSe:]CURRent[:DC]:NPLCycles? MAX
Query the maximum value.
Details
Refer to Integration time and resolution for DC and resistance measurements (on page 3-41) for more
information about NPLC.
[SENSe:]CURRent[:DC]:RANGe <n>|MIN|MAX
Use this command to select the function (DCI) and set a measure range.
Parameters
<n> description
-10 to 10 Select the measurement range in amps.
MINimum
Select the minimum value.
MAXimum
Select the maximum value.
Query
command description
[SENSe:]CURRent[:DC]:RANGe?
Query the measurement range.
[SENSe:]CURRent[:DC]:RANGe? MIN
Query the minimum range.
[SENSe:]CURRent[:DC]:RANGe? MAX
Query the maximum range.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
