Keithley 2110 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 1:
Introduction
2110-901-01 Rev. C/August 2013 1-7
Function Default
Diode test
Digits
5.5
Range
1 mA
Rate
0.2 PLC
Resistance
Digits
5.5 (1 PLC)
Range
1 k
Ω
Temperature
Digits
4.5 (1 PLC)
Thermocouple
K type
Triggers
Source
Immediate
Delay
Auto
Input resistance
10 M
Ω
General specifications
Item Limitation and description
Input bias current <30 pA at 25 °C
Input protection 1000 V all ranges (2W input)
AC CMRR
70 dB (for 1 kΩ unbalanced LO lead)
Power supply 100 V, 120 V, 220 V (230 V), 240 V ±10%
Power line frequency 50/60 Hz auto detected ±10%
Power consumption 25 VA maximum
Digital I/O interface USB-compatible type B connection, GPIB (optional)
Environment For indoor use only
Operating temperature 0 °C to 40 °C
Operating humidity Maximum relative humidity 80% for temperature up to 31 °C
Storage temperature -40 °C to 70 °C
Operating altitude Up to 2000 m above sea level
Bench dimensions
107 mm high × 252.8 mm wide × 305 mm deep (3.49 in. × 9.95 in. ×
12.00 in.)
(with handles and bumpers)
Weight 2.23 kg (4.92 lb)
Safety Conforms to European Union Low Voltage Directive
UL listed to UL 61010-1: 2004
Pollution degree
2
EMC
Conforms to European Union EMC Directive
Warranty One year

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
