5: Remote commands Model 2110 5½ Digit Multimeter
5-14 2110-901-01 Rev. C/August 2013
:CONFigure:<function>
[<range>|MIN|MAX|DEF,<resolution>|MIN|MAX|DEF]
This command configures the instrument to a specific setup for a specified measurement function. This command
does not initiate the measurement. The :READ? command can be used to trigger a measurement. You can also
use the INIT;:FETC? command.
Parameters
All <range> and <resolution> parameters also include MIN, MAX, and DEF. N/A indicates that the
<range> and/or <resolution> parameters are not applicable for the <function>.
<function> <range> <resolution> (see note 1) Description (see
note 2)
1. Do not use the number of digits to specify a resolution; instead, use the same units as the
measurement function. For example, specify the resolution in volts and the frequency in hertz. You
must multiply the resolutions in the table by the needed range before using them as resolution
arguments. Refer to Bandwidth and resolution for AC measurements (on page 3-44) for more
information about AC measurements. Refer to Integration time and resolution for DC and resistance
measurements (on page 3-41) for information about DC measurements.
2. Information listed in the description column is for reference only. This column lists the
measurement unit for the <function>. Do not include units in commands.
