Keithley 2110 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 5:
Remote commands
2110-901-01 Rev. C/August 2013 5-15
Query
Command Description
CONFigure?
Query the selected function.
Details
The CONFigure command offers a little more flexibility than the MEASure? command. The multimeter sets the
parameters for the requested function, range and resolution. You have an option to change the configuration.
The CONFigure command does not initiate the measurement. To initiate the measurement, use INITiate or
READ? command.
When this command is sent, the instrument will be configured as follows:
• The function specified by this command is selected.
• The range and resolution are selected as specified.
• All other controls related to the selected function are defaulted to the *RST values.
This command is automatically asserted when the :MEASure? command is sent.
Example
CONF:VOLT[:DC] 10,0.001
Configure 1 mV resolution digits on the 10 VDC range.
CONF:FREQ 1KHz,0.1Hz
Configure 1000 Hz input, 0.1 Hz resolution.
Also see
:INITiate (on page 5-16)
:READ[1|2]? (on page 5-17)
:FETCh[1|2]? (on page 5-16)

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
