Keithley 2110 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 5:
Remote commands
2110-901-01 Rev. C/August 2013 5-17
:READ[1|2]?
The READ? command changes the state of the trigger system from the idle state to the wait-for-trigger state.
When the specified trigger condition requirements are met after the instrument receives the READ? command,
the measurement is initiated. The result is sent to the output buffer immediately. You must enter the reading data
into your bus controller or the instrument will stop making measurements when the output buffer fills. Readings
are not stored in the instrument’s internal memory when using the READ? command.
To take many samples quickly, use INIT;:FETC?.
Variations
READ1?
Initiates the trigger model and transfers the readings from the primary measurement function
to the output buffer.
READ2?
Initiates the trigger model and transfers the readings from the secondary measurement
function to the output buffer.
Example
:READ2?
Also see
:INITiate (on page 5-16)
:FETCh[1|2]? (on page 5-16)

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
