Keithley 2110 User Manual

Section
5: Remote commands Model 2110 5½ Digit Multimeter
Reference Manual
5-40 2110-901-01 Rev. C/August 2013
[SENSe:]CURRent[:DC]:RANGe:AUTO <b>
This command turns DC current autorange on or off.
Parameters
<b> description
0 or OFF
Turn autorange off.
1 or ON
Turn autorange on.
Query
command description
CURRent[:DC]:RANGe:AUTO?
Query autorange state.
[SENSe:]DETector:BANDwidth <n>|MIN|MAX
Use this command to specify the lowest frequency expected in the input signal. The instrument selects the slow,
medium or fast AC filter based on the frequency you specify.
Parameters
<n> description
3 Slow AC filter. 3 Hz. A value less than 3 will error. A floor calculation is
performed.
20
Medium AC filter. 20 Hz.
200
Fast AC filter. 200 Hz. This is the default value.
MINimum
Select the minimum value.
MAXimum
Select the maximum value.
Query
command description
[SENSe:]DETector:BANDwidth?
Query the bandwidth.
[SENSe:]DETector:BANDwidth? MIN
Query the minimum bandwidth.
[SENSe:]DETector:BANDwidth? MAX
Query the maximum bandwidth.
Details
Refer to Bandwidth and resolution for AC measurements (on page 3-44) more information about bandwidth.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
