5: Remote commands Model 2110 5½ Digit Multimeter
Reference Manual
5-18 2110-901-01 Rev. C/August 2013
:MEASure[:<function>]?
<range>|MIN|MAX|DEF,<resolution>|MIN|MAX|DEF
This command configures the specified function, range, and resolution, and then returns a single measurement.
Parameters
All <range> and <resolution> parameters also include MIN, MAX, and DEF. N/A indicates that the
<range> and/or <resolution> parameters are not applicable for the <function>.
<function> <range> <resolution> (see note 1) Description (see
note 2)
CURRent[:DC]
-10 to 10
3.00e-07 to 3.00e-04
Amperes
CURRent:AC
0 to 10
1.00e-06 to 1.00e-04
Amperes
VOLTage[:DC]
-1000 to 1000
3.00e-07 to 3.00e-04
Voltage
VOLTage:AC
0 to 750
1.00e-06 to 1.00e-04
Voltage
CAPacitance
0 to 10e-3
N/A
Farads
VOLTage[:DC]:RATio
-1000 to 1000
3.00e-07 to 3.00e-04
Voltage
RESistance
0 to 100e6
3.00e-07 to 3.00e-04
Ohms
FRESistance
0 to 100e6
3.00e-07 to 3.00e-04
Ohms
FREQuency[:VOLTage]
0 to 750
N/A
Voltage
FREQuency:CURRent
0 to 10
N/A
Amperes
PERiod[:VOLTage]
0 to 750
N/A
Voltage
PERiod:CURRent
0 to 10
N/A
Amperes
CONTinuity
N/A
N/A
N/A
DIODe
N/A
N/A
N/A
TCOuple
N/A
N/A
N/A
TEMPerature
N/A
N/A
N/A
1. Do not use the number of digits to specify a resolution; instead, use the same units as the
measurement function. For example, specify the resolution in volts and the frequency in hertz. You
must multiply the resolutions in the table by the needed range before using them as resolution
arguments. Refer to Bandwidth and resolution for AC measurements (on page 3-44) for more
information about AC measurements. Refer to Integration time and resolution for DC and resistance
measurements (on page 3-41) for information about DC measurements.
2. Information listed in the description column is for reference only. This column lists the
measurement unit for the <function>. Do not include units in commands.
Details
This command combines all of the other signal oriented measurement commands to perform a single
measurement and acquire the reading.
Although it does not offer much flexibility, using the MEASure? command is the simplest way to program the
instrument for measurements. You specify the measurement function, range and resolution, the instrument
automatically sets the other parameters for you, make the measurement and send the result to the output buffer.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
