Thermocouple measurements
The following table lists the temperature range for the supported thermocouple (TC) types:
Thermocouple temperature measurement ranges
Thermocouple type
Temperature range (
°
C) Temperature range (
°
F)
B
600 to 1820
1112 to 3308
C
0 to 2316
32 to 4200.8
E
-250 to 1000
-418 to 1832
J
-210 to 1200
-346 to 2192
K (default)
-200 to 1372
-328 to 2501.6
N
-200 to 1300
518 to 2372
R
0 to 1767
32 to 3212.6
S
0 to 1767
32 to 3212.6
T
-250 to 400
-418 to 752
Configuration settings for thermocouple temperature measurements:
• Thermocouple type: B, C, E, J, K, N, R, S, T
Default setting: K
• Measurement units: °C or °F
Default setting: °C
• Reference junction: Real or simulated
Default setting: Real
A thermocouple measurement is referenced to a known temperature. The reference junction can be real
or simulated.
For a real reference junction, the instrument performs a temperature measurement on a built-in cold
junction compensator and uses that reading as the reference point for subsequent thermocouple
measurements.
For a simulated reference junction, you enter a temperature reading to use as the reference
temperature. An ice bath is typically used in determining a simulated reference junction.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
