Section 3: Functions and features Series 2280 Precision DC Power Supply Reference Manual
3-46 077085503 / March 2019
Step mode triggering
In step mode, the instrument generates a measure complete signal after each list step. You can
detect this signal in digital I/O line 2. For details, refer to Digital I/O (on page 3-19).
Figure 75: Step mode triggering
As shown in the previous figure, the device action can be any mode described in List running time (on
page 3-44). The measurement time is set accordingly.
