9-14 Sweep Operation Models 2500 and 2502 User’s Manual

Custom sweep commands

Table 9-4 summarizes remote commands used for custom sweep operation. See

Section 17, “Conﬁgure list,” for more details on these commands.

Table 9-4

Custom sweep commands

Command Description

:SOURce[1]:VOLTage:MODE LIST

:SOURce[1]:LIST:VOLTage < list>

:SOURce[1]:LIST:VOLTage:APPend <list>

:SOURce[1]:LIST:VOLTage:POINts?

:SOURce[1]:SWEep:RANGing <name>

:SOURce2:VOLTage:MODE LIST

:SOURce2:LIST:VOLTage < list>

:SOURce2:LIST:VOLTage:APPend <list>

:SOURce2:LIST:VOLTage:POINts?

:SOURce2:SWEep:RANGing <name>

Select channel 1 voltage list (custom) sweep mode.

Deﬁne Ch. 1 V-source list (list = V1, V2,… Vn).

Add Ch. 1 V-source list value(s) (list =V1, V2,…Vn).

Query length of Ch. 1 V-source list.

Select Ch. 1 source ranging (name = BEST, AUTO, or

FIXed).

Select channel 2 voltage list (custom) sweep mode.

Deﬁne Ch. 2 V-source list (list = V1, V2,… Vn).

Add Ch. 2 V-source list value(s) (list =V1, V2,…Vn).

Query length of Ch. 2 V-source list.

Select Ch. 2 source ranging (name = BEST, AUTO, or

FIXed).
