17-16 SCPI Command Reference Models 2500 and 2502 User’s Manual
Command Description
Default
parameter SCPI
:SOURce2
:VOLTage
:STARt <n>
:STARt?
:STOP <n>
:STOP?
:STEP <n>
:STEP?
:SPAN <n>
:SPAN?
:CENTer <n>
:CENTer?
:SWEep
:SPACing <name>
:SPACing?
:POINts <n>
:POINts?
:DIRection <name>
:DIRection?
:RANGing <name>
:RANGing?
:LIST
:VOLTage <NRf>
:APPend <NRf>
:POINts?
:VOLTage?
Path to configure channel 2 source (continued):
Specify start level for V-sweep; -100 to 100.
Query start level for voltage sweep.
Specify stop level for V-sweep; -100 to 100.
Query stop level for voltage sweep.
Specify step value for V-sweep; -200 to 200.
Query step value for voltage sweep.
Specify span; -200 to 200.
Query span.
Specify center point; -100 to 100.
Query center point.
Configure SWEep source mode:
Select sweep spacing type (LINear or LOGarithmic).
Query sweep spacing.
Specify number of sweep points (2 to 3000).
Query number of points in sweep.
Sweep from start to stop (UP) or from stop to
start (DOWN).
Query sweep direction.
Select source ranging mode (BEST, AUTO, or
FIXed).
Query source ranging mode.
Configure LIST source mode:
Create list of V-Source values; -100 to 100.
Add up to 100 V-Source values to end of list.
Query number of source values in list.
Query V-Source list.
0
0
0
0
0
LINear
3000
UP
BEST
No effect
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Table 17-6 (continued)
SOURce command summary
