7-12
Status Structure
Models 2510 and 2510-AT User’s Manual
Figure 7-4
Standard event status
DDE
(B3)
QYE
(B2)
—
(B1)
OPC
(B0)
EXE
(B4)
CME
(B5)
URQ
(B6)
PON
(B7)
—
(B15 - B8)
Standard Event
Status Enable
&
&
&
&
&
&
OR
T
o Event
Summary Bit
(ESB) of Status
Byte Register
.
(See Figure
7-1.)
PON = Power On
URQ = User Request
CME = Command Error
EXE = Execution Error
*ESE
&
DDE
(B3)
QYE
(B2)
—
(B1)
OPC
(B0)
EXE
(B4)
CME
(B5)
URQ
(B6)
PON
(B7)
—
(B15 - B8)
Standard Event
Status Register
*ESR?
DDE = Device-Dependent Error
QYE = Query Error
OPC = Operation Complete
& = Logical AND
OR = Logical OR
120
122
