3-4 Basic Operation Models 2510 and 2510-AT User’s Manual
12. Choose PID, then press ENTER.
13. Program your PROPORTIONAL, INTEGRAL, and DERIVATIVE constants as
required.
14. After programming, press EXIT as necessary to return to normal display.
Table 3-1
Temperature configuration menu
Configuration
menu item Description
PROTECTION
CONTROL
LOLIM
HILIM
Configure temperature protection.
ENABLE or DISABLE temperature protection.
Program lower limit (-50 to +250°C; 223.15 to 523.15K; -58 to +482°F).*
Program higher limit (-50 to +250°C; 223.15 to 523.15K; -58 to +482°F).*
SENSOR-TYPE
THERMISTOR
RANGE
A
B
C
I-SRC
SENSE-MODE
RTD
TYPE
α
β
δ
RANGE
I-SRC
SENSE-MODE
ISS
OFFSET
SCALE-FACTOR
VSS
OFFSET
SCALE-FACTOR
Select sensor type and settings.
Program thermistor settings.
Set thermistor range (100
Ω
, 1k
Ω
, 10k
Ω
, 100k
Ω
).
Program A coefficient (-10 to +10).
Program B coefficient (-10 to +10).
Program C coefficient (-10 to +10).
Set thermistor current (AUTO, 3.3µA, 10µA, 33.3µA, 100µA, 833.3µA, 2.5mA).
Select 2-WIRE or 4-WIRE sense mode.
Program RTD sensor parameters.
Select PT385, PT3916, PT100, D100, F100, USER type. Program USER
α
,
β
,
δ
.
Program USER alpha (0 to 0.01).
Program USER beta (0 to 1).
Program USER delta (0 to 5).
Set RTD range (100
Ω
or 1000
Ω
).
Set RTD current (AUTO, 3.3µA, 10µA, 33.3µA, 100µA, 833.3µA, 2.5mA).
Select 2-WIRE or 4-WIRE sense mode.
Program current solid-state sensor settings.
Program offset (K), -999.999 to 999.999
Program slope (K/A), 0 to 9.999e-4
Program voltage solid-state sensor settings.
Program offset (K), -999.999 to 999.999
Program slope (K/A), 0 to 9.999e-2
UNITS
Select temperature units (°C, Kelvin, °F).
PID
PROPORTIONAL
INTEGRAL
DERIVATIVE
Program PID loop constants for temperature.
Set proportional constant (0 to 100000).
Set integral constant (0 to 100000).
Set derivative constant (0 to 100000).
*Lower limit cannot be set higher than higher limit. Higher limit cannot be set lower than lower limit.
