Models 2510 and 2510-AT User’s Manual SCPI Command Reference 10-5
Table 10-4
:SENSe[1] subsystem commands
Command Description Default parameter SCPI
[:SENSe[1]] ✓
:CURRent[:DC] Path to configure DC current. ✓
:PROTection Set current protection. ✓
[:LEVel] <n> Set protection current level.
<n> = 1.0 to 5.25 (A) | MIN | MAX | DEF.
2.0 ✓
[:LEVel]? Query protection current level. ✓
:TRIPped? Query if protection level exceeded.
(1 = tripped.)
✓
:RESistance Path to configure resistance. ✓
:CURRent <n> Set RTD or thermistor sensor current.
<n> = 3e-6 to 1e-3 (3.3e-6, 1e-5, 3.33e-5,
1e-4, 8.333e-4, 2.5e-3) | MIN | MAX | DEF.
2.5e-3 (100Ω range)
8.333e-4 (1kΩ range)
1e-4 (10kΩ range)
3.33e-5 (100kΩ range)
:AUTO <b> Enable/disable default sensor current
(ON | OFF).
ON
:AUTO? Query default sensor current state.
:CURRent? Query sensor current.
:TRANsducer
<name>
Select sensor type.
<name> = THERmistor | RTD
THERmistor
:TRANsducer? Query transducer type.
:THERmistor
RANGe <n> Set thermistor resistance range. <n> = 0 to 3e5
(100, 1e3, 1e4, 1e5) | MIN | MAX | DEF.
1e4
RANGe? Query thermistor resistance range.
:RTD
:RANGE<n>
:RANGe?
Set RTD sensor range <n> = 0 to 1000
(100, 1000) | MIN | MAX | DEF.
Query RTD resistance range.
100
:TEMPerature Path to configure temperature.
:CURRent <n> Set RTD or thermistor sensor current.
<n> = 3e-6 to 1e-3 (3.3e-6, 1e-5, 3.33e-5,
1e-4, 8.333e-4, 2.5e-3) | MIN | MAX | DEF
2.5e-3 (100Ω range)
8.333e-4 (1kΩ range)
1e-4 (10kΩ range)
3.33e-5 (100kΩ range)
:AUTO <b> Enable/disable auto sensor current
(ON | OFF).
ON
:AUTO? Query auto default sensor current state.
:CURRent? Query sensor current.
:TRANsducer
<name>
Select transducer (sensor) type.
<name> = THERmistor | RTD | VSS | ISS
THERmistor
:TRANsducer? Query transducer type.
:RTD Program RTD type and coefficients.
:TYPE <name> Select RTD sensor type. <name> = PT385,
PT3916, PT100, D100, F100, or USER.
PT385
