8-2 Common Commands Models 2510 and 2510-AT User’s Manual
Command summary
Common commands (summarized in Table 8-1) are device commands that are common to
all devices on the bus. These commands are designated and defined by the IEEE-488.2
standard. Most of these commands are described in detail in this section.
NOTE The following common commands associated with the status structure are cov-
ered in “Status Structure,: Section 7: *CLS, *ESE, *ESE?, *ESR?, *SRE,
*SRE?, and *STB?.
Table 8-1
IEEE-488.2 common commands and queries
Mnemonic Name Description
*CLS Clear status Clears all event registers and Error Queue.
1
*ESE <NRf> Event enable command Program the Standard Event Enable Register.
1
*ESE? Event enable query Read the Standard Event Enable Register.
1
*ESR? Event status register query Read and clear the Standard Event Enable Register.
1
*IDN? Identification query Returns the manufacturer, model number, serial
number, and firmware revision levels of the unit.
*OPC Operation complete command Set the Operation Complete bit in the Standard
Event Register after all pending commands have
been executed.
*OPC? Operation complete query Places an ASCII “1” into the Output Queue when all
pending selected device operations have been
completed.
*OPT? Option query Returns summary of installed options.
*RCL <NRf> Recall command Returns the Model 2510 to the user-saved setup.
*RST Reset command Returns the Model 2510 to the *RST default condi
tions.
*SAV <NRf> Save command Saves the present setup as the user-saved setup.
*SRE <NRf> Service request enable command Programs the Service Request Enable Register.
1
*SRE? Service request enable query Reads the Service Request Enable Register.
1
*STB? Status byte query Reads the Status Byte Register.
1
*TRG Trigger command Sends a bus trigger to the Model 2510.
*TST? Self-test query Performs a checksum test on ROM and returns the
result.
*WAI Wait-to-continue command Wait until all previous commands are executed.
1
Status commands are covered in “Status Structure,” Section 7.
