Models 2510 and 2510-AT User’s Manual Getting Started 1-23
Table 1-5
Temperature configuration menu
Configuration menu item Description
PROTECTION
CONTROL
LOLIM
HILIM
Configure temperature protection.
ENABLE or DISABLE temperature protection.
Program lower temperature limit.
Program higher temperature limit.
SENSOR-TYPE
THERMISTOR
RANGE
A
B
C
I-SRC
SENSE-MODE
RTD
TYPE
RANGE
I-SRC
SENSE-MODE
I-SS
OFFSET
SCALE-FACTOR
V-SS
OFFSET
SCALE-FACTOR
Select sensor type and settings.
Program thermistor settings.
Set thermistor range (100Ω, 1kΩ, 10kΩ, 100kΩ).
Program A coefficient.
Program B coefficient.
Program C coefficient.
Set thermistor current (AUTO, 3.3µA, 10µA, 33.3µA, 100µA, 833.3µA,
2.5mA).
Select 2-WIRE or 4-WIRE sense mode.
Program RTD sensor parameters.
Select PT385, PT3916, PT100, D100, F100, USER type. Program USER α,
β, δ.
Set RTD range (100Ω or 1000Ω).
Set RTD current (AUTO, 3.3µA, 10µA, 33.3µA, 100µA, 833.3µA, 2.5mA).
Select 2-WIRE or 4-WIRE sense mode.
Program current solid-state sensor settings.
Program offset (K).
Program slope (K/A).
Program voltage solid-state sensor settings.
Program offset (K).
Program slope (K/A).
UNITS Select temperature units (°C, Kelvin, °F).
PID
PROPORTIONAL
INTEGRAL
DERIVATIVE
Program PID loop constants for temperature control.
Set proportional constant.
Set integral constant.
Set derivative constant.
