Models 2510 and 2510-AT User’s Manual Getting Started 1-13
Display examples
Typical display examples are shown in Table 1-1.
Table 1-1
Display examples
Function Display toggle sequence*
Temperature +025.000°C
Setpoint: +025.000°C PEL:-00.072V
+025.000°C
Setpoint: +025.000°C PEL:-0.0030A
+025.000°C
Setpoint: +025.000°C PEL:+00.002W
+025.000°C
Setpoint: +025.000°C PEL:+002.40Ω
+025.000°C
Setpoint: +025.000°C RT:+000.04kΩ
Voltage +01.000V
Setpoint: +01.000V T:+030.630°C
+01.000V
Setpoint: +01.000V PEL:+0.3689A
+01.000V
Setpoint: +01.000V PEL:+00.368W
+01.000V
Setpoint: +01.000V PEL:+002.71Ω
+01.000V
Setpoint: +01.000V RT:+000.04kΩ
Current +00.500A
Setpoint: +00.500A T:+033.200°C
+00.500A
Setpoint: +00.500A PEL:+01.377V
+00.500A
Setpoint: +00.500A PEL:+00.689W
+00.500A
Setpoint: +00.500A PEL:+002.75Ω
+00.500A
Setpoint: +00.500A RT:+002.75kΩ
