Models 2510 and 2510-AT User’s Manual SCPI Command Reference 10-11
:SOURce[1]
✓
:STOLerance Program setpoint tolerance parameters.
[:PERCent] <n> Percentage of range.
<n> = 0.00-100.00 (%) | MIN | MAX | DEF
0.5
[:PERCent]? Query percent of range value.
:POINts? Query number of points currently within
tolerance.
:COUNt <n> Number of points in tolerance window.
<n> = 1-100 | MIN | MAX | DEF
5
:COUNt? Query number of points.
:VOLTage Voltage source commands. ✓
:LCONstants Set voltage PID loop constants.
[:GAIN] <n> Program voltage loop gain.
<n> = 0 to 1e5 | MIN | MAX | DEF
10.0
[:GAIN]? Query voltage loop gain.
:DERivative <n> Set voltage derivative constant.
<n> = 0 to 1e5 | MIN | MAX | DEF
0.0
:DERivative? Query voltage derivative constant.
:INTegral <n> Set voltage integral constant.
<n> = 0 to 1e5 | MIN | MAX | DEF
20.0
:INTegral? Query voltage integral constant.
[:LEVel] ✓
[:IMMediate] ✓
[:AMPLitude] <n> Set voltage amplitude.
<n> = -10 to +10 (V) | MIN | MAX | DEF
0.0 ✓
[:AMPLitude]? Query voltage amplitude. ✓
:PROTection ✓
[:LEVel] <n> Set voltage limit.
<n> = 0.5 to +10.5 (V) | MIN | MAX | DEF
10.5 ✓
[:LEVel]? Query voltage limit. ✓
:TRIPped? Query if limit exceeded. (1 = tripped;
0 = otherwise).
✓
Table 10-6
:SOURce2 subsystem commands
Command Description
Default
parameter SCPI
:SOURce2 Path to SOURce2 subsystem.
:TTL
[:LEVel] <NRf> or <NDN> Specify the four bit Digital I/O port output value. 15
[:LEVel]? Query digital output line logic levels.
Table 10-5 (continued)
:SOURce[1] subsystem commands
Command Description Default parameter SCPI
