3-8 Basic Operation Models 2510 and 2510-AT User’s Manual
Configuring output
Using Table 3-5 as a guide, configure the output as follows:
1. Press CONFIG then OUTPUT to enter the output configuration menu.
2. Choose GND-CONNECT, then press ENTER.
3. ENABLE or DISABLE ground connect as required, then press ENTER.
4. If you are using the output enable circuit (see Section 5), select ENABLE, then
press ENTER. Select ENABLE from the OUTPUT ENABLE menu, then press
ENTER again.
5. Press EXIT to return to normal display.
Configuring setpoint tolerance
Using Table 3-6 as a guide, follow the steps below to configure setpoint tolerance. See
“Setpoint tolerance,” page 3-15, for more details.
1. Press CONFIG, then any one of the four EDIT keys to access the setpoint tolerance
menu.
2. From the SETPOINT TOLERANCE MENU, select PERCENTAGE, then press
ENTER.
3. Choose PERCENTAGE, then press ENTER.
4. Using the EDIT keys, set the percentage to the desired value, then press ENTER.
5. Choose WINDOW-SIZE, then press ENTER.
6. Use the EDIT keys to set the number of readings to be within the tolerance win-
dow, then press ENTER.
7. Press EXIT to return to normal display.
Table 3-5
Output configuration menu
Configuration menu item* Description
GND-CONNECT
DISABLE
ENABLE
Select input/output analog common (ground) connection.
Disable ground connection.
Enable ground connection.
ENABLE
DISABLE
ENABLE
Enable/disable Digital I/O port output enable line.
Inactivate output enable line.
Activate output enable line.
*See Section 2 for information on reversal and ground connect modes.
*See “Output enable line,” page 5-6, for output enable information.
