3-16 Basic Operation Models 2510 and 2510-AT User’s Manual
Ranges
Ranges by function are shown in Table 3-9.
Operation
To configure the setpoint tolerance feature from the front panel, press CONFIG followed
by any one of the four EDIT keys (, , , ). The unit will display the setpoint tolerance
configuration menu. (See “Configuring setpoint tolerance,” page 3-8, and Table 3-6.) Use
the EDIT, ENTER, and EXIT keys to set the percent tolerance and window size as
required.
Setpoint tolerance indicator
The front panel “*” annunciator will turn on when the output is within the setpoint toler-
ance for the programmed number of readings. The unit can also be programmed to gener-
ate an SRQ when setpoint tolerance is reached via bit 12 (SPT) of the Measurement Event
Register. See “Status Structure,” page 7-1, for details.
Table 3-9
Setpoint tolerance ranges
Function Range
Temperature 275°C
275K
495°F
Voltage 20V
Current 10A
Resistance 200kΩ (100kΩ thermistor)
80kΩ (10kΩ thermistor)
10kΩ (1kΩ thermistor or RTD)
1kΩ (100Ω thermistor or RTD)
