Models 2510 and 2510-AT User’s Manual Basic Operation 3-5
Configuring voltage
Using Table 3-2 as a guide, configure the voltage source as follows:
1. Press CONFIG then V to access the voltage configuration menu.
2. Select PROTECTION, then press ENTER.
3. Using the EDIT keys, set the voltage limit to the desired value, then press ENTER.
4. Choose PID, then press ENTER.
5. Program the PROPORTIONAL, INTEGRAL, and DERIVATIVE constants as
required.
6. After programming, press EXIT as necessary to return to normal display.
Configuring current
Using Table 3-3 as a guide, configure the current source as follows:
1. Press CONFIG then I to enter the current configuration menu.
2. Select PROTECTION, then press ENTER.
3. Using the EDIT keys, set the current limit to the desired value, then press ENTER.
4. Choose PID, then press ENTER.
5. Program the PROPORTIONAL, INTEGRAL, and DERIVATIVE constants as
required.
6. Press EXIT to return to normal display.
Table 3-2
Voltage source configuration menu
Configuration menu item Description
PROTECTION Set voltage protection limit (0.5 to +10.5V).
PID
PROPORTIONAL
INTEGRAL
DERIVATIVE
Program PID loop constants for voltage.
Set proportional constant (0 to 100000).
Set integral constant (0 to 100000).
Set derivative constant (0 to 100000).
Table 3-3
Current source configuration menu
Configuration menu item Description
PROTECTION Set current protection limit (1.00 to 5.25A).
PID
PROPORTIONAL
INTEGRAL
DERIVATIVE
Program PID loop constants for current.
Set proportional constant (0 to 100000).
Set integral constant (0 to 100000).
Set derivative constant (0 to 100000).
