1-18 Getting Started Models 2510 and 2510-AT User’s Manual
Setting Front panel BENCH and GPIB default*
Current function
Setpoint 0A
Current protection limit 2A
Proportional constant 10
Integral constant 20
Derivative constant 0
Resistance function
Setpoint 100Ω (100Ω RTD or thermistor)
1kΩ (1kΩ RTD or thermistor)
10kΩ (10kΩ thermistor)
100kΩ (100kΩ thermistor)
Protection high limit 200Ω (100Ω RTD or thermistor)
2kΩ (1kΩ RTD or thermistor)
20kΩ (10kΩ thermistor)
200kΩ (100kΩ thermistor)
Protection low limit 50Ω (100Ω RTD or thermistor)
500Ω (1kΩ RTD or thermistor)
5kΩ (10kΩ thermistor),
50kΩ (100kΩ thermistor)
Protection state Enabled
Sensor current 2.5mA (100Ω range )
833.3µA (1kΩ range)
100µA (10kΩ range)
33.3µA (100kΩ range)
Sensor current auto state On
Sensor type Thermistor
Sense mode 2-wire
Thermistor range 10kΩ
Proportional constant 20
Integral constant 0.6
Derivative constant 0
Output On/Off Off
Digital I/O enable line Off
Peltier (cooler) ground connect mode Disabled
Digital I/O port output value 15
Display format** Engineering units
Setpoint tolerance percentage 0.5%
Window size 5
** BENCH defaults are the same as :SYSTem:PRESet defaults (Section 10). GPIB defaults are the same
as *RST defaults (Section 8).
** Not affected by BENCH or GPIB RESET.
Table 1-3 (continued)
Factory front panel default settings
