Section 2: General operation Model 2657A High Power System SourceMeter® Instrument Reference Manual
2-14 2657A-901-01 Rev. B/December 2012
Press the EXIT key to return to a previous menu.
The following table contains descriptions of the configuration menus, as well as cross-references to
related information. To select a menu, press the CONFIG key and then the front-panel key associated
with the menu (see the description column in the following table).
To access, press the CONFIG
key and then:
Options For more information, see:
SRC V-source sense, low range,
protection; sink; I-source low
range
Range (on page 2-72), Basic source-
measure procedure (on page 2-24)
MEAS V-sense and measure low
range; I-measure low range;
and auto-zero
Range (on page 2-72), Basic source-
measure procedure (on page 2-24)
LIMIT V-source and I-source
compliance limits
Compliance limits (on page 2-18)
SPEED Measurement speed (NPLC) Speed (on page 2-78)
REL Set relative values Relative offset (on page 3-1)
FILTER Configure digital filter Filters (on page 3-2)
OUTPUT ON/OFF Set off-state, off-function Output-off states (on page 2-66)
TRIG Set trigger in, count, interval,
and delay
Manual triggering (on page 3-52),
Triggering in local mode
(on page 2-28)
STORE Set buffer mode, count, and
destination
Reading buffers (on page 3-6)
Setting values
Setting a value
You can adjust a value using either the Navigation wheel method or Numeric entry method (using
the keypad).
Navigation wheel method:
1. Use the CURSOR arrow keys (or turn the navigation wheel ) to move the cursor to the digit
that needs to be changed.
2. Press the navigation wheel or the ENTER key to enter edit mode. The EDIT indicator is
illuminated.
3. Rotate the navigation wheel to set the appropriate value.
4. Press the ENTER key to select the value or press the EXIT (LOCAL) key to cancel the change.
5. To return to the main menu, press the EXIT (LOCAL) key.
Numeric entry method:
The numeric entry method may only be used if the numeric keypad is enabled.
Quick Tip
NOTE
